Magnimage
> SKU: MAG.DN9402

MAG.DN9402 is one of Magnimage’s new 4K processor , which is specially designed for large resolution display system.
Adopt the highest level video processing chip,internal 24 bits system ,4K/60HZ 4:4:4 technology . interal system adopt
4K&2K matrix function, support multiple 4K input .

Advanced cross-point image processing technology, make sure no delay and jag, output image more clear and smooth.
Abundant input ,which support max 9 4K channel input. Include 4K DP,DP,12GSDI.

    Consultar precios

    Descripción

    4K Video Wall Controller

    MAG.DN9402 Series


    Admite la gestión de EDID

    Entrada/Salida Puerto único Máx. Ancho 7680px, Máx. Altura 2600px










    Habilidad de capa poderosa

    Capas 4K independientes

    Soporte de salida única Máx. 4 capas 4K independientes

    La capa admite el ajuste de brillo/contraste/temperatura de color








    Cambio continuo entre preajustes








    Salida de monitor

    Salida de toda la máquina, es conveniente que el operador controle el contenido de la pantalla LED en algunas ocasiones en las que la pantalla LED no se puede ver directamente.








    HDR10






    Subtítulos de desplazamiento






    Varias formas de control








    Input Spec

    Input Type Qty Resolution
    DP1.2 4 3840×2160/60Hz、7680×1080/60Hz and EDID Management
    HDMI2.0 4 3840×2160/60Hzand EDID Management
    12G SDI 1 3840×2160/60Hz and downward compatibility



    Output Spec
    Output Type Port Qty Resolution
    Main OUT HDMI2.0 4×2 3840×2160/60Hz and EDID Management
    Monitoring OUT HDMI1.3 1 1920×1080/60Hz



    Machine Spec
    Power input 100-220V AC 50/60Hz
    Consumption 90W
    Product dimensions 482.6×446.3×92.5mm
    Net weight 6.7Kg



    MIG-DN9402 series brief 1.0 Descargar
    MIG-DN9402 Software 1.0.0.2 Descargar
