Extensores de fibra con soporte HDMI 1.4 M1-HDMI1.4

Extensores de fibra de soporte HDMI 1.4

Resolución de soporte hasta 4K@60 4: 2: 0
Soporte de modo único óptico
Soporte de HDCP 2.2 y EDID transparente
Distancia de soporte hasta 300 metros con un solo cable LC.

    Consultar precios

    ⓘ PRECIOS SIN IVA

    Descripción

    Extensores de fibra de soporte HDMI 1.4

    Resolución de soporte hasta 4K@60 4: 2: 0
    Soporte de modo único óptico
    Soporte de HDCP 2.2 y EDID transparente
    Distancia de soporte hasta 300 metros con un solo cable LC.

    Especificaciones


    Name Specification
    Product Name One core single mode HDMI1.4 Fiber extender +RJ45
    Model M1-HDMI1.4
    Brand Beetek
    Signal HDMI 1.4
    Input Connector TX :HDMI Type A Female, RJ45 *2 ;
    RX:Single-core LC
    Output Connector TX :Single-core LC;
    RX: HDMI Type A Female, RJ45 *2
    Locking HDMI Port Yes
    Fiber Interface Dust Prevention Yes
    Fiber Type Single-mode G657.A1
    Indicator LED Signal, Power, Network port and Hot-plug 4 way indicator
    Locking power connector Yes
    Power Consumption TX:DC 12V 2A RX:DC 5V
    Ambient Temp -20°C ~ 70°C
    Material Metal mold
    Dimensions TX:185 *95 *26mm; RX:125 *70 *26mm
    Weight TX : 0.53kg ; RX: 0.35kg
    Package Dimensions 270 *157 *136mm
    Packaging Weight 1.3kg
    DDC Yes
    Ethernet Supports bidirectional 100M Ethernet
    HDMI Audio Yes
    3D Yes
    CEC Yes
    ARC Yes
    HDCP Yes
    XvYCC Color Space Yes
    Optical Module 1*12G ,2*2.5G 3-channel single-mode optical module
    Technical Characteristics Circuit Multiplexing SerDes Technology, 3-wave CWDM Technology
    Optical module life 100,000 Hours
    Resolution 3840×2160@30Hz
    Transmission Distance Single-mode 300M
    Clock Bandwidth 340MHz *3
    Transmission Speed 10.2Gbps
    Balancing Chip Automatic equalization
    Reclocking Yes
    ESD Protection Yes
    Hot Plug Yes
    Delay Zero-frame
    Compression None
    Sampling Rate Bandwidth Range: 8~16bit
    Sampling Ratio RGB 4:4:4 , YUV 4:4:4, YUV 4:2:2, YUV 4:2:0
