Line Club – Elokance

The elokance Line Array portable LINE Club diffusion system combines new technologies and performance.

Its vertical configuration ensures optimal sound quality even over long distances, a clear response and controlled directivity.

Its modular design makes installation simple and quick. The vertical elements (1 booster and 2 high frequency satellites) are very fast to implement, making this audio system a truly complete all-in-one broadcasting system, perfect for all your performances: Conferences, meetings, live music, DJ….

Its subwoofer with two 12″ boomers loaded in bass-reflex provides a precise and powerful low frequency response.

In addition to its on-board Bluetooth connectivity, the LINE Club includes a real mixing console and a USB-type charging socket to recharge your mobile devices.

Like the other elokance brand audio systems, the LINE Club is equipped with a high-end, over-protected Class-D amplifier, ensuring reliability and durability.

  • Compact line array sound system Elokance Line Club
  • Low bass drivers: 12″ (38cm)
  • Low bass HP coil: 3″.
  • Tweeters: 4 x 3″ neodymium tweeters
  • Tweeter coil: 0.8″.
  • Bass reflex system
  • Amplifier: Class D
  • RMS amplification power 500W
  • Amplification power MAX 1000W
  • Amplification power PEAK 1500W
  • SPL Max: 121 dB
  • SPL Peak: 130 dB
  • Frequency response @ -3dB : 30Hz-20kHz
  • Frequency response @ -10dB : 25Hz-20kHz
  • Cut-off frequency: 200 Hz
  • Dispersion: 120°x20°
  • Audio Signal Processing via DSP, 4-channel mixer, Bluetooth receiver
  • USB connector for charging your smartphone battery
  • Stereo pairing button for use with 2 stereo systems
  • Optional transport covers
  • Power consumption: 150W
  • Subwoofer dimensions: 370x450x450x450 mm
  • Satellite box dimensions: 515x84x84x110 mm
  • NET subwoofer weight: 15 kg
  • NET satellite weight: 3.25 kg
    • Consultar precios

      ⓘ PRECIOS SIN IVA

      Descripción

      The elokance Line Array portable LINE Club diffusion system combines new technologies and performance.

      Its vertical configuration ensures optimal sound quality even over long distances, a clear response and controlled directivity.

      Its modular design makes installation simple and quick. The vertical elements (1 booster and 2 high frequency satellites) are very fast to implement, making this audio system a truly complete all-in-one broadcasting system, perfect for all your performances: Conferences, meetings, live music, DJ….

      Its subwoofer with two 12″ boomers loaded in bass-reflex provides a precise and powerful low frequency response.

      In addition to its on-board Bluetooth connectivity, the LINE Club includes a real mixing console and a USB-type charging socket to recharge your mobile devices.

      Like the other elokance brand audio systems, the LINE Club is equipped with a high-end, over-protected Class-D amplifier, ensuring reliability and durability.

    • Compact line array sound system Elokance Line Club
    • Low bass drivers: 12″ (38cm)
    • Low bass HP coil: 3″.
    • Tweeters: 4 x 3″ neodymium tweeters
    • Tweeter coil: 0.8″.
    • Bass reflex system
    • Amplifier: Class D
    • RMS amplification power 500W
    • Amplification power MAX 1000W
    • Amplification power PEAK 1500W
    • SPL Max: 121 dB
    • SPL Peak: 130 dB
    • Frequency response @ -3dB : 30Hz-20kHz
    • Frequency response @ -10dB : 25Hz-20kHz
    • Cut-off frequency: 200 Hz
    • Dispersion: 120°x20°
    • Audio Signal Processing via DSP, 4-channel mixer, Bluetooth receiver
    • USB connector for charging your smartphone battery
    • Stereo pairing button for use with 2 stereo systems
    • Optional transport covers
    • Power consumption: 150W
    • Subwoofer dimensions: 370x450x450x450 mm
    • Satellite box dimensions: 515x84x84x110 mm
    • NET subwoofer weight: 15 kg
    • NET satellite weight: 3.25 kg
    •

      Line array
       Non

      Integrated mixer
       Yes

      Tweeter
       3″ x8

      Acoustic pressure (dB)
       From 120 to 130

      Effects
       Audio signal processed by DSP

      Streaming
       Bluetooth

      Peak power (W)
       1500

      RMS power (W)
       500

      Subwoofer included
       Yes

      Color
       Black

      Connectors
       XLR female 3 pins, Jack female Mono, Mini Jack female stereo, RCA female

      Weight
       18,4 kg

      Application
       Ambiance, Mobile DJ, Festival, Live, Restaurant

      Amplification type
       Class D

      Power supply
       220 V

      Vertical dispersion °
       20°

      Horizontal dispersion °
       120°

      Speaker
       12″

      Frequency response, low limit
       30 Hz

      Frequency response, upper limit
       20 kHz
