MXi.6FX

Topp Pro
> > SKU: MXi.6FX

6 Input Mixer

2 MIC/Line inputs – 2 Stereo Line Inputs

24-bit Digital FX Processor / 100 Presets

    Consultar precios

    ⓘ PRECIOS SIN IVA

    Descripción

    Especificaciones

    Model MXi.6FX
    Input Channels
    Mono input channels
    Microphone input electronically balanced, discrete input configuration
    Frequency response 10 Hz to 55 kHz, +/ 3 dB
    Distortion (THD & N) 0.005% at +4 dBu, 1 kHz
    Gain range 0 dB to 60 dB (MIC)
    SNR (Signal to Noise Ratio) 115 dB
    Line input electronically balanced
    Frequency response 10 Hz to 55 kHz, +/ 3 dB
    Distortion (THD & N) 0.005% at +4 dBu, 1 kHz
    Stereo input channels
    Line input Balanced
    Frequency response 10 Hz to 55 kHz, +/- 3 dB
    Distortion (THD & N) 0.005% at +4 dBu, 1 kHz
    Impedance
    Microphone Input 1.4 k Ohms
    All Other Input 10k Ohms or Greater
    Tape Out 1k Ohms
    All Other Outputs 120 Ohms
    Equalization
    Hi shelving +/- 15 dB @12 kHz
    Mid bell +/- 15 dB @ 2.5 kHz
    Low shelving +/- 15 dB @ 80 Hz
    DSP Section
    A/D and D/A converters 24-bit
    DSP resolution 24-bit
    Type of effects Vibraflange, Funky, Rockabilly, Bigstage, Vibrato1-4,Flanger1-4, Chorus1-4
    Presets 16
    Controls 16-position PRESET Selector, FX level, REVERB level, CLIP LED
    Main Mix Section
    Noise (Bus Noise) Fader 0dB,Channels muted:-100dBr (ref:+4dBu)
    Fader 0dB, All Input Channels Assigned and Set To UNITY Gain:-90dBr(ref:+4dBu)
    Max Output +22 dBu Unbalanced,1/4′ Jacks
    AUX Sends max out +22 dBu
    AUX Returns gain range 8 to +15 dB
    Power Supply(AC/DC Adaptor)
    Main voltage USA / Canada 100-120 V~, 60 Hz
    Fuse Europe 210-230 V~, 50 Hz, U.K. / Australia 240 V~, 50 Hz
    Power Consumption 15 Watts
    Physical
    Dimension (W D H) 185 mm x 230 mm x 35/55 mm
    Net weight 1.4 Kg (3.09 lb)
    Shipping weight 2.7 Kg (5.95 lb)
