MXi.1222CFX

Topp Pro
> > SKU: MXi.1222CFX

12 Input Mixer

4 Compressors control

Built in 24-bit DSP effect with 100 presets

Assembled MP3 Player

    Consultar precios

    ⓘ PRECIOS SIN IVA

    Descripción

    Especificaciones

    Mono channels
    Microphone input XLR with balanced
    Frequency response 10Hz to 55KHz,+/-3dB
    Distortion (THD+N) <0.03% at +0dB ,22Hz~22KHz A-weighted
    Gain range 0dB to 50dB
    Max. Input +21 dB
    LOW CUT 75Hz
    SNR <-100dBr A-weighted
    Phantom power +48V with switch control
    Line input 1/4” TRS with balanced
    Frequency response 10Hz to 55KHz,+/-3dB
    Distortion (THD+N) <0.03% at +0dB ,22Hz~22KHz A-weighted
    Sensitivity range +20dB~ -30dB
    Compressor GAIN: 0~9dB / THRESHOLD: 20dB—>5dB
    Stereo input channels
    Mic input XLR with balanced
    Line input 1/4′ TRS with balanced
    Frequency response 10Hz to 55KHz, +/-3dB
    Distortion (THD+N) <0.03% at +0dB ,22Hz~22KHz A-weighted
    Sensitivity range +20dBu~ -30dBu
    SNR <-100dBr A-weighted
    RCA input channels
    RCA input RCA with un-balanced
    Frequency response 10Hz to 55KHz,+/-3dB
    Distortion (THD+N) <0.03% at +0dB ,22Hz~22KHz A-weighted
    Sensitivity range +20dBu~ -30dBu
    SNR <-100dBr A-weighted
    Channels EQ
    Channel Mono / Stereo
    High +/-15dB @12KHz / +/-15dB @12KHz
    Mid +/-15dB @100KHz -8KHz / +/-15dB @3KHz or +/-15dB @500Hz
    Low +/-15dB @80Hz / +/-15dB @80Hz
    Impedances
    Microphone input 1.8K Ω
    All other input 10K Ω or greater
    Tape out 1K Ω
    All other out 120 Ω
    DSP section (options)
    A/D and D/A converters 24bit
    Type of effects Vocal, Small Room, Large Hall, Echo, Echo+Verb, Flange+Verb, Plate, Chorus+GTR, Rotary+GTR, Tremolo+GTR
    Controls 100 position preset selector(10 preseter * 10 variation), Mute switch & Foot-switching with LED indicator
    FOOT-SW TIP: FX – SLEEVE: GND
    Main mix section
    Max. MAIN MIX output +26dBu XLR balanced (+20dBu un-balanced)
    AUX range OFF to +10dB
    Fader range OFF to +10dB
    PHONES/CONTROL-ROOM range OFF to +10dB
    Hum & Noise <-80dB @ 20Hz~22KHz A-weighted, 1 channel & MAIN level:0dB, the other: Minimum
    Crosstalk <-80dB @ 0dB 20Hz~22KHz A-weighted, MAIN level:0dB, the other :minimum
    Power supply
    Main voltage 100-240V~ 50/60Hz
    Fuse T1.25A AC250V
    Rated power consumption 30W
