DM48.20

Topp Pro
> > SKU: DM48.20

32-XLR Mic Inputs

20-XLR Auxiliary Outputs

XLR- Main Out

Headphones Out

Digital Inserts

17 Motorized Multi-Use Faders

OLED Name Strips

External Plug-In Processing

4 Multi-Effects Engines

10″ Touchscreen

Rec / Play to USB Key

Sends on Faders

16 DCA Groups

Automix

    Consultar precios

    ⓘ PRECIOS SIN IVA

    Descripción

    Especificaciones

    Microphone input Electronically balanced
    Frequency Response to Main Output 22Hz ~ 20KHz at 0dBu ±1.5dBu
    Distortion (THD&N) to Main Output <0.03% at 0dBu 1KHz
    Gain 0dBu ~ 50dBu
    SNR (Signal to Noise Ratio) 109dB
    Maximum Input Level +20dBu ±0.5dBu
    Phantom Power (+/-3V) +48VDC
    USB stereo inputs 22Hz ~ 22KHz at 0dBu ±1.5dBu
    Frequency Response to Main Output <0.03% at 0dBu 1KHz
    Distortion (THD&N) to Main Output 10dBu ±0.5dBu
    Maximum Input Level +20dBu ±0.5dBu
    Out 1-16
    Maximum Outputs Level +20dBu ±0.5dBu
    Main Outputs
    Maximum Output Level +20dBu ±0.5dBu
    Control Room Outputs
    Maximum Output Level +20dBu ±0.5dBu
    Noise Gate
    Threshold Range -80d0Bu ~ -30dB
    Attack time 0.5mS ~ 200mS
    Release time 10mS~1S
    Compressor
    Threshold Range -30dBu – +20dB
    Attack time 10mS ~ 150mS
    Release time 10mS ~ 1S
    Ratio 1:1 to Limit
    Gain 0dBu – +20dB
    EQ
    Low (LowPass or LowShelf) 21Hz ~ 19.2KHz ±(24dBu±2dBu)
    Low Mid 21Hz ~ 19.2KHz ±(24dBu±2dBu)
    High Mid 21Hz ~ 19.2KHz ±(24dBu±2dBu)
    High (HighPass or HighShelf) 21Hz ~ 19.2KHz ±(24dBu±2dBu)
    Digital Audio
    ADC Dynamic Range 114dB
    DAC Dynamic Range 114dB
    Internal Processor 32-bit , floating point
    ADC, DAC bit depth 24bit
    Main LCD 10.1 inch (1024×600)
    Channel LCD 0.96 inch (128×64)
    Impedances
    Microphone input 6.8K Ohm
    All output 120 Ohm
    Operating free-air temperature range 0ºC ~ 40ºC
    Storage temperature range -20ºC ~ 45ºC
