HVA4.150

Power 70V (RMS)
150W x 4 (One Channel Driven) – 135W x 4 (All Channel Driven)
Power 100V (RMS)
150W x 4 (One Channel Driven) – 135W x 4 (All Channel Driven)
Input Sensitivity (Limiter Off)
0.9 – 1.1V (+0/-1dBv)

    Consultar precios

    Descripción

    Especificaciones

    HVA4.150
    Power 70V (RMS) 150W x 4 (One Channel Driven) – 135W x 4 (All Channel Driven)
    Power 100V (RMS) 150W x 4 (One Channel Driven) – 135W x 4 (All Channel Driven)
    Input Sensitivity (Limiter Off) 0.9 – 1.1V (+0/-1dBv)
    Input Impedance 20KΩ balanced or 10KΩ unbalanced
    Frequency Response 100Hz~15KHz (+0/-3dB) (At 10dB Below Output Power)
    Voltage Gain (100V) 40 (+0/-1dB)
    THD + N <0.1% (Ref. 1KHz 1/8 Rated Power, A-Weighted)
    S/N Ratio >95dB (Ref. Rated Power, A-Weighted)
    Crosstalk (Below Rated Power) >70dB
    Damping Factor (1KHz, 8W) >200
    Power/Output Circuity Switching Power Class-D
    Protections Full short circuit, open circuit, thermal, ultrasonic, and RF protection stable into reactive or mismatched loads, turn ON/OFF, muting, tried crowbar.
    Controls Front: On/Off Power Switch, Volume Channel A, B / Rear 70/100V selector
    Indicators SIGNAL: 4 green LED – CLIP & PROTECTION 4 red LED / POWER: 1 green LED
    Connectors Inputs: Euro Block – Outputs: Euro Block
    Power Supply AC: 110-120V or 220~240V 50/60Hz
    Dimension (HxWxD) 44 x 483 x 360 mm / 1.73″ x 19.02″ x 14.17″
    Weight 5.4 kg / 11.91 lbs
