VHD1.0 – Mid High/Down-fill Enclosure

KV2AUDIO
SKU: VHD1.0

The VHD1.0 downfill enclosure features a single 12″ low mid woofer, an 8″ transcoil mid-range woofer and the same compression driver as the VHD2.0 on a wide angle 110° horizontal by 40° vertical horn. The rear of the box has been angled for use as a downfill with the VHD2.0. Alternatively as a stand-alone box up to three VHD1.0s can be powered from a single VHD2000 amplifier. Like the VHD2.0, VHD1.0 is available in left and right versions for downfill applications. Designed to be powered as a slave from the VHD2.0 cabinet or directly from the VHD2000 amplifier, all equalization, set up and level are preset providing a plug and play solution for large scale touring and high quality installation.

Applications

Designed as a true mid high – downfill enclosure to accompany the VHD2.0 as part of the VHD systems

  • Medium to large concert venues
  • Fixed installation
  • Outdoor events

Product code

  • KVV 987 141 – VHD1.0 R (right)
  • KVV 987 076 – VHD1.0 L (left)


    Consultar precios

    Descripción

    The VHD1.0 downfill enclosure features a single 12″ low mid woofer, an 8″ transcoil mid-range woofer and the same compression driver as the VHD2.0 on a wide angle 110° horizontal by 40° vertical horn. The rear of the box has been angled for use as a downfill with the VHD2.0. Alternatively as a stand-alone box up to three VHD1.0s can be powered from a single VHD2000 amplifier. Like the VHD2.0, VHD1.0 is available in left and right versions for downfill applications. Designed to be powered as a slave from the VHD2.0 cabinet or directly from the VHD2000 amplifier, all equalization, set up and level are preset providing a plug and play solution for large scale touring and high quality installation.

    Features

    • Professional Baltic birch construction with wear-resistant polymer coating
    • Cut away down angle for correct positioning when flown underneath VHD2.0 cabinet
    • Four pieces of fly-track (two per side)
    • Very High Definition audio reproduction
    • 134dB sustained output, 137dB peak
    • Controlled wide dispersion 110° x 40° Mid/High horn with a flat response to 180°
    • Revolutionary 3″ (76 mm) Nitride Titanium diaphragm compression driver with complex geometry phase plug and neodymium magnetic structure for higher output, exceptionally low distortion and extended frequency response
    • 8″ Trans-Coil midrange driver, with a 3″ (76 mm) voice coil and neodymium magnet for increased control and output with reduced distortion and weight. Horn loaded 12″ mid-bass driver with 3″ (76 mm) inside/outside, epoxy baked, high temperature voice coil assembly and neodymium magnetic structure
    • Three way active requirement – 1000W from the VHD 2000 providing 600W for the 12″ Low Mid, 300W for the 8″ Midrange and 100W for the High Frequency
    • Proprietary side handle design (3) for simplified handling and carrying
    • High impact low friction feet, allowing lock- in to other VHD cabinets and easy cabinet movement
    • Front locking aluminium VHD wheel boards with wraparound hardwood bumpers
    • Weather proofing option and special paint finishes available on request


    YouTube thumbnailYouTube icon

    Applications

    Designed as a true mid high – downfill enclosure to accompany the VHD2.0 as part of the VHD systems

    • Medium to large concert venues
    • Fixed installation
    • Outdoor events

    Product code

    • KVV 987 141 – VHD1.0 R (right)
    • KVV 987 076 – VHD1.0 L (left)


    VHD Basics



    Description

    Basic usage of speakers, left and right side of the system. VHD 1.0 can be used as downfill with single VHD 2.0 configurations or other applications as recommended by KV2 Audio Tech support.



    Products

    Count Product Type
    1 VHD2.0 MID-HI
    1 VHD1.0 MID-HI


    Accessories

    Count Accessory Title
    1 Cable MH15 Cable MH15
    1 Cable MH120 Cable MH120


    Images

    VHD1.0



    Description

    Up to 2000 people Number of bass boxes – depend on music style Right side of stereo single system For live system 4x 2.16 Subs recommended



    Products

    Count Product Type
    1 VHD1.0 MID-HI
    4 VHD4.18 SUB
    1 VHD2000 MID-HI AMP
    1 VHD3200 SUB AMP


    Accessories

    Count Accessory Title
    1 Cable MH120 Cable MH120
    2 Cable LF15 Cable LF15
    2 Cable LF40 Cable LF40


    Images



    Cable MH120

    Gallery

    Product code

    KVV 987 126



    Description

    – 6 wire speaker cable – AP6 connectors – 12m (40ft) length – for Mid/Hi Module hook-up



    Cable MH15

    Gallery

    Product code

    KVV 987 147



    Description

    – 6 wire speaker cable – AP6 connectors – 1,5m (5ft) length – for Mid/Hi Module connection – for VHD1.0 Mid/Hi Module daisy-chaining



    Cable MH180

    Gallery

    Product code

    KVV 987 127



    Description

    – 6 wire speaker cable – AP6 connectors – 18m (60ft) length – for Mid/Hi Module hook-up



    Mid/Hi speaker cable MH60

    Gallery

    Product code

    KVV 987 125



    Description

    – 6 wire speaker cable – AP6 connectors – 6m (20ft) – for Mid/Hi Module hook-up



    VHD1.0 Cart

    Gallery

    Product code

    KVV 987 156



    Description

    – cart for easy transport and hanging VHD1.0 – with hardwood bumpers
    – wheels are included



    Downloads

    DWG

    VHD1.0 Cart 3D DWG

    VHD1.0 Cart 3D DWG

    SKP

    VHD1.0 Cart SketchUp

    VHD1.0 Cart SKP

    VHD1.0 Cover

    Gallery

    Product code

    KVV 987 157



    Description

    – used with cart



    VHD1.0 Downfill arm (pair)

    Gallery

    Product code

    KVV 987 310



    Description

    The VHD1.0 DOWNFILL ARM is a short, flat pre-angled steel bar that has two pre-fixed apertures at the lower end of the bar to allow different angles of suspension from the enclosure above. The arm is attached to the VHD1.0 down-fill enclosure by means of two apertures that receive the insertion of two D6 QUICK RELEASE PINS. The top of the bar is attached to the bottom of either the VHD2.0 TOP ARM or BASS/VHD2.0 ARM by sliding into the groove and inserting a single D12.6 QUICK RELEASE PIN.



    Downloads

    SKP

    VHD1.0 Downfill arm (pair) SKP

    VHD1.0 Downfill arm (pair) SketchUp

    System Acoustic Performance

    Max SPL Long-term 134dB
    Max SPL Peak 140dB
    -3dB Response 100Hz to 22kHz
    -10dB Response 85Hz to 30kHz
    Full Range mode -3dB Response 65Hz to 22kHz
    Crossover Point 100Hz, 450Hz, 2.2kHz

    High Frequency Section

    Acoustic Design Horn Loaded
    Horn Coverage Horizontal / Vertical 110° x 40°
    High Frequency Amplifier Requirement 100W (VHD200 amp.)
    Throat Exit Diameter / Diaphragm Size 1.4″ / 3.0″
    Diaphragm Material Nitride Titanium
    Magnet Type Neodymium

    Mid Range Section

    Acoustic Design Horn Loaded
    Horn Coverage Horizontal / Vertical 110° x 40°
    Midrange Amplifier Requirement 300W (VHD2000 amp.)
    Woofer Size / Voice Coil Diameter 8″ / 3.0″ / Trans Coil
    Diaphragm Material Epoxy Reinforced Cellulose
    Magnet Type Neodymium

    Mid Bass Section

    Acoustic Design Horn Loaded
    Mid-bass Amplifier Requirement 600W (VHD2000 amp.)
    Woofer Size / Voice Coil Diameter 12″ / 3″ / Inside Outside
    Diaphragm Material Epoxy Reinforced Cellulose
    Magnet Type Neodymium

    Speaker Input

    Speaker Input AP6 male

    Speaker Output

    Speaker Output AP6 female

    Cabinet

    Cabinet Material Baltic birch
    Handles 4
    Color Black (wear resistant polymer coating)

    Physical Dimensions

    Height 660 mm (25.98″)
    Width 700 mm (27.55″)
    Depth 495 mm (19.48″)
    Weight 45 kg (99lbs)


    Product code

    • KVV 987 141 – VHD1.0 R (right)
    • KVV 987 076 – VHD1.0 L (left)

    PDF

    VHD2.0, VHD1.0 and Flyware User Guide

    VHD2.0, VHD1.0 and Flyware User Guide, English



    PDF

    VHD1.0 Technical Data Sheet

    Download Product’s Data Sheet


    DWG

    VHD1.0 – 3D

    1:1 scale – clamping points – weight – dwg file



    SKP

    VHD1.0 Downfill arm (pair) SKP

    VHD1.0 Downfill arm (pair) SketchUp



    DWG

    VHD1.0 Downfill arm (pair) 3D DWG

    VHD1.0 Downfill arm (pair) 3D DWG



    SKP

    VHD Systems fly bar SKP

    VHD Systems fly bar SketchUp



    DWG

    VHD Systems fly bar 3D DWG

    VHD Systems fly bar 3D DWG



    SKP

    VHD1.0 Cart SketchUp

    VHD1.0 Cart SKP



    DWG

    VHD1.0 Cart 3D DWG

    VHD1.0 Cart 3D DWG



    SKP

    VHD1.0R (right) SKP

    VHD1.0R (right) SketchUp



    DWG

    VHD1.0R (right) 3D DWG

    VHD1.0R (right) 3D DWG



    SKP

    VHD1.0L (left) SKP

    VHD1.0L (left) SketchUp



    DWG

    VHD1.0L 2D DWG

    VHD1.0L 2D DWG



    DWG

    VHD1.0R 2D DWG

    VHD1.0R 2D DWG



    PDF

    VHD1.0 Right – 2D

    VHD1.0 Right 2D Drawings



    PDF

    VHD1.0 Left – 2D

    VHD1.0 Left 2D Drawings



    SKP

    VHD Series Sketchup

    VHD Series Sketchup – all boxes and accessories



    DWG

    VHD1.0L (left) 3D DWG

    VHD1.0L (left) 3D DWG



    GLL

    VHD2.0 EASE data package

    VHD2.0 EASE data package includes VHD2.0, Double VHD2.0, VHD1.0 standalone, VHD1.0 downfill



    GLL

    VHD2.0 Double EASE Focus

    VHD2.0 Double EASE Focus ver 5



    GLL

    VHD2.0 Single EASE Focus

    VHD2.0 Single EASE Focus ver 5
