QD8 – Stereo 8-band Master Equaliser with Line Driver

KV2AUDIO
SKU: QD8

A revolutionary George Krampera 8-band Equaliser specifically designed to highlight a desired band without adversely affecting the overall sonic landscape. Whilst not intended for tuning out room modes, the frequency bands and filter types have been precisely chosen after extensive research, to perfectly align with the science of human hearing and our perception of achieving the ultimate spectral balance. In a Live scenario, faced with a number of different sources, program types, or performance genres at a festival or concert, the equaliser is very musical, intuitive and an exceptionally quick way to shape any mixed content to the sound you want to hear. In the studio, it can be either the simple enhancement of an instrument / vocal track, or the final mastering polish to take an ordinary mix and make it something very special.

Applications

  • For use in Recording Studios as a master equaliser, single instrument, or group equaliser.
  • Front of House PA system master equaliser, the unit is also equipped with line drivers designed to maintain audio signal integrity over long cable lengths (up to 200 m).
  • Single stereo zone or dual mono system equaliser, to sonically match different fill speakers and zones with the main FOH PA when used in multiples.
  • To reduce the harshness in some digital recordings, particularly around the 6kHz region.

Product code

KVV 987 477



    Consultar precios

    Descripción

    A revolutionary George Krampera 8-band Equaliser specifically designed to highlight a desired band without adversely affecting the overall sonic landscape. Whilst not intended for tuning out room modes, the frequency bands and filter types have been precisely chosen after extensive research, to perfectly align with the science of human hearing and our perception of achieving the ultimate spectral balance. In a Live scenario, faced with a number of different sources, program types, or performance genres at a festival or concert, the equaliser is very musical, intuitive and an exceptionally quick way to shape any mixed content to the sound you want to hear. In the studio, it can be either the simple enhancement of an instrument / vocal track, or the final mastering polish to take an ordinary mix and make it something very special.



    YouTube thumbnailYouTube icon

    Applications

    • For use in Recording Studios as a master equaliser, single instrument, or group equaliser.
    • Front of House PA system master equaliser, the unit is also equipped with line drivers designed to maintain audio signal integrity over long cable lengths (up to 200 m).
    • Single stereo zone or dual mono system equaliser, to sonically match different fill speakers and zones with the main FOH PA when used in multiples.
    • To reduce the harshness in some digital recordings, particularly around the 6kHz region.

    Product code

    KVV 987 477



    System Acoustic Performance

    -3dB Response 10Hz to 100kHz
    Total Harmonic Distortion <0.001%

    Signal Input

    Input Channels 2
    Input Impedance 20 kΩ
    Max. Input voltage +26dBu

    Signal Output

    Signal Output Channels 2
    Output Impedance 50Ω
    Maximal Output Voltage 18dBu (600Ω) RMS
    Maximal Output Current 300mA

    Features

    Equalization 8-band EQ
    Output Line driver

    Power Requirements

    Operating Voltage ±16V
    Power Consumption 160mA

    Physical Dimensions

    API Series 500 format One slot


    Product code

    KVV 987 477


    PDF

    500 Series User Guide

    500 Series User Guide – TCL, QD8, MPA (English)



    PDF

    QD8 2D PDF

    QD8 2D PDF


    PDF

    QD8 Download Product’s Data Sheet

    Download Product’s Data Sheet


    DWG

    QD8 2D DWG

    QD8 2D DWG


    SKP

    QD8 3D SKP

    QD8 SKP


    DWG

    QD8 2D DWG

    QD8 2D DWG


    DWG

    QD8 3D DWG

    QD8 3D DWG
