ESP2000D Amplifier with Control & Diagnostics Tool

KV2AUDIO
SKU: ESP2000D

The ESP2000D is a two channel rack mountable power amplifier. The unit contains two separate 1000 watt amplifiers, two independent power supplies, (each channel running off each power supply), two signal paths, inputs and outputs as well as limiting and low frequency enhancement on each of the two channels within a two rack unit chassis. It can be used to power any range of passive loudspeakers as well as being specifically designed for optimised performance with KV2 Audio’s ESD Series. ESP2000D is now configurable via the front panel or remotely using KV2 Control & Diagnostics Tool.

Applications

Designed to drive the ESD and ESM range of passive loudspeaker units with superior sound quality featuring KV2 Control & Diagnostics Tool

  • Portable PA
  • Fixed installations

Product code

  • KVV 987 412 – ESP2000D (250V)
  • KVV 987 411 – ESP2000D (230V)
  • KVV 987 410 – ESP2000D (115V)


    Consultar precios

    Descripción

    The ESP2000D is a two channel rack mountable power amplifier. The unit contains two separate 1000 watt amplifiers, two independent power supplies, (each channel running off each power supply), two signal paths, inputs and outputs as well as limiting and low frequency enhancement on each of the two channels within a two rack unit chassis. It can be used to power any range of passive loudspeakers as well as being specifically designed for optimised performance with KV2 Audio’s ESD Series. ESP2000D is now configurable via the front panel or remotely using KV2 Control & Diagnostics Tool.

    Features

    • Very high definition
    • 2 channel rack mountable power amplifier
    • 2 x 1000W / 2Ω
    • Separate power supplies ensure increased reliability and continuous delivery of full power
    • Two shock mounted fans move air across the fins but never directly across the electronic components. Minimises maintenance cycles and improves the components lifespan and reliability
    • Configurable via the front panel or remotely using KV2 Control & Diagnostics Tool


    YouTube thumbnailYouTube icon

    Applications

    Designed to drive the ESD and ESM range of passive loudspeaker units with superior sound quality featuring KV2 Control & Diagnostics Tool

    • Portable PA
    • Fixed installations

    Product code

    • KVV 987 412 – ESP2000D (250V)
    • KVV 987 411 – ESP2000D (230V)
    • KVV 987 410 – ESP2000D (115V)


    Accesories


    2 Channel Adapter Cable

    Gallery

    Product code

    KVV 987 450



    Description

    – 2 channel adapter cable



    System Acoustic Performance

    -1dB Response 3Hz to 40kHz
    Channel Crosstalk >70dB
    Signal to Noise Ratio >115dB
    Total Harmonic Distortion <0.005% (1W) / <0.01% (clip -1dB)

    Output Channels

    Amplifier Type High Efficiency, Emitter coupled
    Number of Channels 2
    Total Output Power 2000W
    Max. Output Voltage 78V (peak) per channel
    Max. Output Current 48A (peak) per channel
    Minimum load impedance per channel
    Out. Power 16Ω – 1 channel / 2 channels loaded 175W / 160W (RMS)
    Out. Power 8Ω – 1 channel / 2 channels loaded 340W / 300W (RMS)
    Out. Power 4Ω – 1 channel / 2 channels loaded 600W / 500W (RMS)
    Out. Power 2Ω – 1 channel / 2 channels loaded 1000W / 800W (RMS)
    Out. Power 16Ω – bridged 600W (RMS)
    Out. Power 8Ω – bridged 1000W (RMS)
    Out. Power 4Ω – bridged 1500W (RMS), 2000W short term

    Signal Input

    Input Channels XLR
    Input Sensitivity 1.55V
    Input Impedance 20kΩ (balanced)
    Signal Output XLR Through Out

    Speaker Output

    Speaker Output Neutrik Speakon®, 2x Binding posts

    Features

    Level Control -24 to +6 dB
    Loudness bass enhancement +6dB @ 60Hz
    RMS Limiter On / Off
    Indicators Power ON/Thermal, Signal/Limiter
    Network Ethernet: SNMP, Webserver

    Power Requirements

    Power Connector Neutrik PowerCon®
    Operating Voltage 115V / 230V / 250V
    Operating Voltage Range 100 to 120V@60Hz | 205 to 240V@50Hz | 225 to 260V@50Hz
    Recommended Amperage 20A 115V | 10A 230V | 10A 250V
    Soft Start YES
    Protection Thermal breaker
    Cooling 2x temperature controlled fans

    Physical Dimensions

    Height 88 mm (3.5″), 2RU
    Width 483 mm (19.00″)
    Depth 496 mm (19.5″)
    Weight 18,8 kg (41,23 lbs)


    Product code

    • KVV 987 412 – ESP2000D (250V)
    • KVV 987 411 – ESP2000D (230V)
    • KVV 987 410 – ESP2000D (115V)
