ES1.5 – Compact Active-Driven Subwoofer
The ES1.5 is a single 15″, extremely compact, high output subwoofer weighing just 30.8 kg (67.9lbs) designed as part of the ES Series speaker system. Used singularly or in multiples of up to three, alongside a single ES1.0 mid high cabinet, the system is powered by the EPAK2500/R Amplifier ensuring fast, easy set up with perfect balance and complete control. The EPAK2500/R also allows up to two ES1.5’s to be used alongside an ES1.8, where the ES1.5 can either be flown alongside an ES1.0 or ground stacked with the ES1.8.
Applications
Specifically designed to accompany and compliment the ES1.0 as a true full range compact system
- Portable PA
- Fixed Installations
- Bars and Nightclubs
- Houses of worship
- Can be integrated with other ES subwoofers
Product code
- KVV 987 003 – ES1.5
Descripción
The ES1.5 is a single 15″, extremely compact, high output subwoofer weighing just 30.8 kg (67.9lbs) designed as part of the ES Series speaker system. Used singularly or in multiples of up to three, alongside a single ES1.0 mid high cabinet, the system is powered by the EPAK2500/R Amplifier ensuring fast, easy set up with perfect balance and complete control. The EPAK2500/R also allows up to two ES1.5’s to be used alongside an ES1.8, where the ES1.5 can either be flown alongside an ES1.0 or ground stacked with the ES1.8.
Features
- Professional Baltic birch construction with highly resistant polymer coating
- 127dB sustained output / 130dB peak per unit and 134dB / 137dB peak when using 3 units
- Acoustic loading via Asymmetrical Bandpass
- 15″ bass driver with 3″ (76 mm) inside/outside, epoxy baked, high temperature voice coil assembly and ferrite magnetic structure
- Proprietary side handle design for simplified handling and carrying
- High-impact low friction feet, asymmetrically located on three sides allowing vertical or horizontal system set up, lock-in and easy cabinet movement
- Four internal corner braces tied to eight M10 suspension points.
A total of 24 suspension points are available for custom installation applications - Weather proofing option and special paint finishes available on request
Applications
Specifically designed to accompany and compliment the ES1.0 as a true full range compact system
- Portable PA
- Fixed Installations
- Bars and Nightclubs
- Houses of worship
- Can be integrated with other ES subwoofers
Product code
- KVV 987 003 – ES1.5
Configurations
ES Single – A1
ES Single – A2
ES Single – A3
ES Single – B1ES Single – A1
Description
Up to 1000 people. Number of bass boxes and SUB LEVEL setup depend on music style. One side of stereo single system.
Note: Selection of ES amplifier model style is optional (either EPAK2500 or EPAK2500R).
Products
Accessories
| Count | Accessory | Title |
|---|---|---|
| 1 | Cable LF40 | Cable LF40 |
| 1 | Cable MH60 | Mid/Hi speaker cable MH60 |
Images
Front view
WiringES Single – A2
Description
Up to 1000 people. Number of bass boxes depends on music style. One side of stereo single system.
Note: Selection of ES amplifier model style is optional (either EPAK2500 or EPAK2500R).
Products
Accessories
| Count | Accessory | Title |
|---|---|---|
| 1 | Cable MH60 | Mid/Hi speaker cable MH60 |
| 1 | Cable LF40 | Cable LF40 |
| 1 | Cable LF15 | Cable LF15 |
Images
Front view
WiringES Single – A3
Description
Up to 1000 people. Number of bass boxes depends on music style. One side of stereo single system.
Note: Selection of ES amplifier model style is optional (either EPAK2500 or EPAK2500R).
Products
Accessories
| Count | Accessory | Title |
|---|---|---|
| 1 | Cable MH60 | Mid/Hi speaker cable MH60 |
| 1 | Cable LF40 | Cable LF40 |
| 2 | Cable LF15 | Cable LF15 |
Images
Front view
WiringES Single – B1
Description
Up to 1000 people. Number of bass boxes depends on music style. One side of stereo single system.
Note: Selection of ES amplifier model style is optional (either EPAK2500 or EPAK2500R).
Products
Accessories
| Count | Accessory | Title |
|---|---|---|
| 1 | Cable MH60 | Mid/Hi speaker cable MH60 |
| 1 | Cable LF40 | Cable LF40 |
| 2 | Cable LF15 | Cable LF15 |
Images
Front view
WiringAccesories
Additional arms for Bracket- Amphenol AP4 connector
- Amphenol AP4 connector
- Cable LF100
- Cable LF15
- Cable LF200
- Cable LF40
- Cart Wheels
- ES System flybar and bracket
- ES1.0, ES1.5 Cart
- ES1.0, ES1.5, ESD15 Horizontal bracket
- ES1.0, ES1.5, ESD15, EX15 Vertical bracket
- ES1.5 Cover
- Short joining bracket for ES System
Additional arms for Bracket
Amphenol AP4 connector
Amphenol AP4 connector
Cable LF100
Cable LF15
Cable LF200
Cable LF40
Cart Wheels
ES System flybar and bracket
ES1.0, ES1.5 Cart
ES1.0, ES1.5, ESD15 Horizontal bracket
ES1.0, ES1.5, ESD15, EX15 Vertical bracket
ES1.5 Cover
Short joining bracket for ES SystemES1.0, ES1.5, ES1.8, ES2.5, ES2.6 Bracket additional arms
Gallery
Product code
KVV 987 192
Description
– 2 pcs ARMS OF FB-0002
– 8 pcs M10 screws
– 8 pcs Quick-lock-pins 6mm included
Downloads
ES1.0, ES1.5, ES1.8, ES2.5, ES2.6 Bracket additional arms 3D DWG
ES1.0, ES1.5, ES1.8, ES2.5, ES2.6 Bracket additional arms 3D DWG
ES1.0, ES1.5, ES1.8, ES2.5, ES2.6 Bracket additional arms SKP
ES1.0, ES1.5, ES1.8, ES2.5, ES2.6 Bracket additional arms SketchUp
EPAK2500, EPAK2500R, ES1.5, ES1.8, ES2.5, ES2.6, SL2.15 Amphenol AP4 connector
Gallery
Product code
KVV 987 048
Description
– female – cable mount
EPAK2500, EPAK2500R, ES1.5, ES1.8, ES2.5, ES2.6, SL2.15 Amphenol AP4 connector
Gallery
Product code
KVV 987 049
Description
– male – cable mount
Cable LF100 for bass speaker
Gallery
Product code
KVV 987 123
Description
– 4 wire speaker cable – AP4 connectors – 10m (33ft) – for ES Bass Module hook-up
Cable LF15
Gallery
Product code
KVV 987 121
Description
– 4 wire speaker cable – AP4 connectors – 1,5m (5ft) – for ES Bass Module daisy-chaining
Cable LF200 for bass speaker
Gallery
Product code
KVV 987 124
Description
– 4 wire speaker cable – AP4 connectors – 20m (66ft) – for ES Bass Module hook-up
Cable LF40
Gallery
Product code
KVV 987 122
Description
– 4 wire speaker cable – AP4 connectors – 4m (13ft) – for ES Bass Module hook-up
ES1.0, ES1.5, EX1.8, EX2.2 Cart wheels
Gallery
Product code
KVV 987 031
Description
– with bolts nuts kit – 4 pcs in pack, rotating, blue
– 16x M8x 25mm Screw Countersunk Hexagon Socket Head
– 16x Nut Hexagon with blue plastic insert M8
Downloads
ES1.0, ES1.5, EX1.8, EX2.2 Cart wheels 3D DWG
ES1.0, ES1.5, EX1.8, EX2.2 Cart wheels 3D DWG
ES1.0, ES1.5, EX1.8, EX2.2 Cart wheels SKP
ES1.0, ES1.5, EX1.8, EX2.2 Cart wheels SketchUp
ES System flybar and bracket
Gallery
Product code
KVV 987 191
Description
– 8 pcs M10 screws – 8 pcs Quick-lock-pins 6mm included – 4 pcs Quick-lock-pins 1/2inch included
Downloads
ES System flybar and bracket 3D DWG
ES System flybar and bracket 3D DWG
ES System flybar and bracket SKP
ES System flybar and bracket SketchUp
ES System flybar and bracket 2D DWG
ES1.0, ES1.5 Cart
Gallery
Product code
KVV 987 030
Description
– for 2pcs ES1.0 or ES 1.5 – wheels not included
– 16x M8x 25mm Screw Countersunk Hexagon Socket Head
– 16x Nut Hexagon with blue plastic insert M8
Downloads
ES1.0, ES1.5 Cart 3D DWG
ES1.0, ES1.5 Cart 3D DWG
ES1.0, ES1.5 Cart SKP
ES1.0, ES1.5 Cart SketchUp
ES1.0, ES1.5, ESD15 Horizontal bracket
Gallery
Product code
KVV 987 035
Description
Horizontal bracket for ES1.0, ES1.5, ESD15 (or eventually for EX15 when positioned vertically) – including top hat cover adaptor plate and two connection bolts – black
Downloads
ES1.0, ES1.5, ESD15 Horizontal Bracket 3D DWG
ES1.0, ES1.5, ESD15 Horizontal Bracket 3D DWG
ES1.0, ES1.5, ESD15 Horizontal Bracket SKP
ES1.0, ES1.5, ESD15 Horizontal Bracket SketchUp
ES1.0, ES1.5, ESD15, EX15 Vertical bracket
3D view
Gallery
Product code
KVV 987 032
Description
Vertical bracket for ES1.0, ES1.5, ESD15, EX15 – including two connection bolts – black
Downloads
ESD15 / ES1.0 / ES1.5 / EX15 Vertical Bracket 2D DWG
ESD15 / ES1.0 / ES1.5 / EX15 Vertical Bracket 2D DWG
ES1.0, ES1.5, ESD15, EX15 Vertical Bracket 3D DWG
ES1.0, ES1.5, ESD15, EX15 Vertical Bracket 3D DWG
ES1.0, ES1.5, ESD15, EX15 Vertical Bracket SKP
ES1.0, ES1.5, ESD15, EX15 Vertical Bracket SketchUp
ES1.5 Cover heavy duty cover
Gallery
Product code
KVV 987 120
Description
– Durable material
Short joining bracket for ES System
Gallery
Product code
KVV 987 027
Description
Short joining bracket for ES System when groundstacked.
Downloads
Short joining bracket for ES system – 2D PDF
Short joining bracket for ES system
Short joining bracket for ES system – 3D DWG
Short joining bracket for ES system – 2D DWG
System Acoustic Performance
| Max SPL Long-term | 127dB (134dB – 3x ES1.5) |
| Max SPL Peak | 133dB (137dB – 3x ES1.5) |
| -3dB Response | 40Hz to 130Hz |
| -10dB Response | 36Hz to 130Hz |
| Impedance | 16Ω |
| Crossover Point | 130Hz |
Low Frequency Section
| Acoustic Design | Twin Asymmetrical loading |
| Low Frequency Amplifier Requirement | 500W / ES1.5 from EPAK 2500/R |
| Woofer Size / Voice Coil Diameter | 15″ / 3″ / Inside Outside |
| Diaphragm Material | Epoxy Reinforced Cellulose |
| Magnet Type | Ferrite |
Speaker Input
| Speaker Input | AP4 |
Speaker Output
| Speaker Output | AP4 |
Cabinet
| Cabinet Material | Baltic birch |
| Handles | 2 |
| Color | “Orange peeled” Matt Black or any RAL |
Physical Dimensions
| Height | 700 mm (27.55″) |
| Width | 450 mm (17.71″) |
| Depth | 450 mm (17.71″) |
| Weight | 35.7 kg (78.7lbs) |
Product code
- KVV 987 003 – ES1.5
