SOHO V8 PLUS

Altavoz pasivo SOHO V8 PLUS de 8″, pensado para instalaciones profesionales en locales comerciales, hostelería y espacios de gran afluencia. Ofrece un sonido potente y definido, con excelente presión sonora y una dispersión amplia que garantiza una cobertura homogénea incluso en entornos ruidosos. Su diseño compacto y robusto permite una integración discreta en pared o suspendido, manteniendo un rendimiento estable y fiable para uso continuo. Ideal como sistema principal o como refuerzo en instalaciones multizona.

    Consultar precios

    ⓘ PRECIOS SIN IVA

    Descripción

    Especificaciones

    Passive Speaker SOHO V8 PLUS
    System Type 3.5″ Passive Speaker System
    Output Power 240W Continuous, 480W Program, 960W Peak
    Sensitivity (1W/1M) 97dB
    Maximum SPL @ 1m 127dB Max. (calculated)
    Frequency Response (-6dB) 140Hz – 20kHz
    Impedance 4 ohms
    Transducer Low 7 x 3.5″ Woofer, 1″ (25.4mm) Voice Coil, 1 x 3.5″ wideband speaker with 1 x 1.35″ coaxial tweeter
    Crossover Frequency 350Hz, 24dB/Oct. ACTIVE
    Dispersion(-6dB) 100° Horizontal
    Enclosure Construction Body In extruded wood, black paint
    Mounting One metal pole-mount, two M8 hanging-points
    Dimensions (HxWxD) 130 x 760 x 103 mm / 5.12″ x 29.92″ x 4.06″
    Net Weight 6.98 Kg / 15.39 Ibs
    Active Subwoofer SOHO S15 SUB
    Subwoofer 1 x 15″ Ø381mm – 2.5″ Voice Coil
    Frequency response -6dB 40Hz-500Hz
    Total amplifier power 1400W PROGRAM / 2800W PEAK Class D @ 4 Ohms
    Amplifier, subwoofer 700W PROGRAM / 1400W PEAK Class D @ 4 Ohms
    Amplifier, satellite/ mid-high unit 700W PROGRAM / 1400W PEAK Class D @ 4 Ohms
    Axial sensitivity 1W@1m 96dB / 130dB Max.
    Electronic Protections Thermal DC / Overload / Digital Compressor / Limit
    Cooling Temperature-controlled fan
    Connections Input: 2 Combo – XLR 1/4″, 1 RCA in L&R / Output: SPK Satellite / XLR Link
    External Controls Volume Control / Switch for Input sens / Swtich for mode selector / Power ON with Green LED / Limiter with Red LED / Ground Lift / IP Control
    Power Supply 115V / 230V Switchable
    Enclosure Construction Plywood cabinet, resistant black paint, metal grille with foam, rubber feet,handles
    Mounting One metal standard 35mm pole-mount
    Dimensions (HxWxD) 520 x 480 x 562 mm / 20.47″ x 18.9″ x 22.13″
    Net Weight 28.3 kg / 62.39 lbs
