COMET

ACME
SKU: XA 2000 FS

El COMET utiliza un motor de luz LED de 1800 W con un modo de alta reproducción cromática, potencia personalizable de 3 niveles, atenuación manual y un rango de zoom de 5° a 15°. Con un soporte estándar, es más fácil de usar. La rueda de color integrada, la rueda de temperatura de color y la rueda verde negativa se pueden combinar para crear múltiples efectos, lo que lo hace ideal para diversos eventos de artes escénicas y proporciona efectos de iluminación posteriores que se adaptan mejor a las necesidades del lugar.

    Consultar precios

    Descripción

    Performance

    Light Source

    1,800W LED engine

    LED Life Expectancy

    20,000 hours

    Total Lumen Output of Fixture

    38,000 lumens

    Color Rendering

    Ra≥95, R9≥90, R15≥95, TLCI≥95, CCI:0-1.2G

    Zoom Range

    5° – 15°

    Diameter of Frontal Lens

    280 mm

    Weight

    51 kg (112.4 lbs)



    Model

    • Model Name: COMET
    • Model Code: XA 2000 FS

    Light Source

    • Light Source: 1,800W LED engine
    • Total Lumen Output of Fixture: 38,000 lumens
    • Color Temperature Output of Fixture: 6,000K
    • Life Expectancy: 20,000 hours*
      *Source manufacturer specification

    Optical System

    • Zoom Range: 5°-15°
    • Color Rendering: Ra≥95, R9≥90, R15≥95, TLCI≥95, CCI:0-1.2G
    • Diameter of Frontal Lens: 280 mm

    Control

    • 26 touch button control panel
    • Display: LCD display
    • Operational Modes: DMX Control,Manual Control
    • Protocols: RDM
    • DMX Protocol Modes: 1
    • Control Channels: 7
    • Firmware Upgrade: Upgrade via DMX link

    Colors

    • 1 Color Wheel: 6 colors, plus open
    • 1 Color Temperature Wheel: 6 color temperature plates
    • 1 Minus Green Wheel: 3 minus-green plates

    Frost Filter

    • 1 frost filter

    Other Effects

    • Smooth dimming 0-100% (4 user selectable dimming curves)
    • Motorized linear iris
    • Manually adjust dimmer
    • Manually adjust frost, focus, zoom and iris
    • Color Rendering: Ra≥95, R9≥90, R15≥95, TLCI≥95, CCI:0-1.2G
    • 1x Color Temperature Wheel: 6 color temperature plates
    • 1x Minus Green Wheel: 3 minus-green plates
    • Power Mode: three power modes

    Electrical and Connectors

    • Input Voltage Range: 180-240Vac; 50/60Hz
    • Power Consumption: 2,180W
    • Power In/Out: Power Cord in
    • Data In/Out: 3-pin or 5-pin XLR

    Physical Information

    • Fixture Dimensions:
      • Width: 493 mm (19.4″)
      • Depth: 1,052 mm (41.4″)
      • Height: 369 mm (14.5″)
      • Weight: 51 kg (112.4 lbs)
    • Fixture Dimensions :
      • With Tripod Stand:
        • Width : 787 mm (31″)
        • Depth : 1,052 mm (41.4″)
        • Height : 1,425 mm (56.1″)
        • Wieght : 74.5 kg (164.2 lbs)

    Packing Information

    • Flight Case Dimensions:
      • Width : 1,195 mm (47.0″)
      • Depth : 625 mm (24.6″)
      • Height : 775 mm (30.5″)
      • Weight :
        • Standard: G.W.: 134.5 kg (296.5 lbs) ( One-pack loader case)

    Work Environment

    • Maximum Ambient Temperature: 40°C
    • Minimum Operating Temperature: 0°C
    • Maximum Surface Temperature: 75°C
    • Protection Rating: IP20

    Approvals

    • CE compliant
    • UKCA compliant

    Installation

    • Horizontal or vertical mounting
    • Universal working position
    • Tripod at the bottom
    • Safety cable attachment point

    Included Items

    • Digital user manual
    • Power



    Dimensions

    Photometrics





    Colors

    Color Wheel: 6 colors, plus open

    Red
    3027002380
    Slot 1

    Green
    3027002379
    Slot 2

    Pink
    3027002378
    Slot 3

    Orange
    3027002381
    Slot 4

    Blue
    3027002377
    Slot 5

    Yellow
    3027002376
    Slot 6

    Color Temperature Wheel: 6 colors, temperature plates

    1/2 Minus green
    3027002382
    Slot 1

    1/4 Minus green
    3027002383
    Slot 2

    1/8 Minus green
    3027002384
    Slot 3

    CTO 2700K
    3027002370
    Slot 1

    CTO 3200K
    3027002371
    Slot 2

    CTO 4000K
    3027002372
    Slot 3

    CTO 4500K
    3027002373
    Slot 4

    CTO 5000K
    3027002374
    Slot 5

    CTO 5600K
    3027002375
    Slot 6





    Prisms/Frost Filters

    1 combinable light frost filter

    Frost Filter





    Descargas


    COMET Descargas Enlace
