GINAMP

GINAMP contiene 800 LED RGB 5050 de 0,3 W, divididos en 40 zonas controlables individualmente con 20 LED en cada segmento, además de los increíbles 48 LED blanco frío de 5 W, divididos en 6 segmentos controlables en el centro. Con un amplio ángulo de visión de 121° desde las zonas de color y un ángulo de 89° desde el tubo blanco, GINAMP está listo para crear un efecto de wash de color y estrobismo dinámico excepcionales.

Las funciones integradas incluyen atenuación suave del 0 al 100 %, mezcla de colores preestablecida, wash de estrobismo dinámico y programas de persecución automática. Ideal para discotecas, salones de baile y cualquier otra aplicación de iluminación para el entretenimiento.

    Consultar precios

    También te recomendamos…

    Descripción

    Performance

    Light Source

    800×0.3W 5050RGB

    48x 5W LED

    LED Life Expectancy

    20,000 hours

    Beam Angle

    RGB LED Zones: 121°

    Strobe Tube: 89°

    Weight

    5.3 kg (11.7 lbs)



    Technical & Specification

    Model

    • Model Name: GINAMP
    • Model Code: STROBE 2

    Light Source

    • Light Source :
      • 800×0.3 W 5,050RGB
      • 48x 5 W LED
    • Life Expectancy: 20,000 hours*
      *Source manufacturer specification

    Optical System

    • Beam Angle :
      • RGB LED Zones: 121°
      • Strobe Tube: 89°

    Control

    • 4 touch button control panel
    • Display: OLED display
    • Operational Modes: DMX Control,Show Mode
    • Protocols: DMX512,RDM
    • DMX Protocol Modes: 5
    • Control Channels: 6/13/18/36/126
    • Firmware Upgrade: Upgrade via DMX link

    Other Effects

    • Outstanding strobe effect with variable speed
    • Smooth dimming 0-100% (4 user selectable dimming curves)
    • High brightness, outstanding washing effect
    • RGB colour mixing
    • 40 x led zones can be controlled individually, 6 x led zones can be controlled in stroboscopic zone

    Electrical and Connectors

    • Input Voltage Range: 100-240Vac; 50/60Hz
    • Power Consumption: 325W
    • Power In/Out: Power connector in/out
    • Data In/Out: 3-pin or 5-pin XLR

    Physical Information

    • Fixture Dimensions:
      • Width: 210 mm (8.3″)
      • Depth: 410 mm (16.1″)
      • Height: 120 mm (4.7″)
      • Weight: 5.3 kg (11.7 lbs)

    Packing Information

    • Carton Dimensions:
      • Width : 285 mm (11.2″)
      • Depth : 210 mm (8.3″)
      • Height : 505 mm (19.9″)
      • Weight :
        G.W.: 6.2 kg (13.7 lbs) (One-pack loader carton)

    Work Environment

    • Maximum Ambient Temperature: 40°C
    • Minimum Operating Temperature: 0°C
    • Maximum Surface Temperature: 65°C
    • Protection Rating: IP20

    Approvals

    • CE compliant

    Installation

    • Horizontal or vertical mounting
    • Universal working position
    • 1 clamp for 50 mm truss
    • 1 x locked points in the handle
    • Safety cable attachment point

    Included Items

    • Digital user manual
    • Power cable
    • Head with handle

    Optional Accessories (With Order Code)

    • Clamp : C-100A (2060001635)
    • Safety Cable: SW-02 (2060000200)
    • Signal Cable: 3-pin or 5-pin signal cable



    Dimensions

    Photometrics



    Video











    Descargas


    GINAMP Descargas Enlace
