Introducing the ACME AECO 30 IP, where brilliance meets excellence. Powered by a 1,800-Watt LED, boasting a total lumen output of 43,000 lumens, a 225 mm frontal lens and a HCRI of Ra≥95, this luminaire produces vivid colors and brilliant lighting effects in every moment..

Immerse yorself in dynamic lighting with a versatile zoom range from 4° to 48°, accompanied by adjustable CTO from 2,700K to 6,200K. Featuring a linear CMY color mixing, dual color wheels, dual rotating gobo wheels, a graphic animation wheel, one 4-facet prism, and two frost filters, the AECO 30 IP presents limitless creative possibilities.

Its IP66 rating ensures extremely versatility for both indoors and outdoors applications. Elevate professional stages, theaters, and outdoor events with captivating lighting effects, delivering unforgettable audio-visual experiences!

    Consultar precios

    También te recomendamos…

    Descripción

    Performance

    Light Source

    1,800W LED engine

    LED Life Expectancy

    20,000 hours

    Total Lumen Output of Fixture

    43,000 lumens

    Variable CTO

    2,700K-6,200K

    Color Rendering

    Ra≥95

    Zoom Range

    4° – 48°

    Diameter of Frontal Lens

    225 mm

    Weight

    52.5 kg (115.7 lbs)



    Technical & Specification

    Model

    • Model Name: AECO 30 IP

    Light Source

    • Light Source: 1,800W LED engine
    • Total Lumen Output of Fixture: 43,000 lumens
    • Color Temperature Output of Fixture: 6,200K
    • Life Expectancy: 20,000 hours*
      *Source manufacturer specification

    Optical System

    • Zoom Range: 4°-48°
    • Color Rendering: Ra≥95, R9≥95, R15≥95;TLCI≥95;TM-30 Rf: 91;TM-30 Rg: 99
    • Diameter of Frontal Lens: 225 mm

    Control

    • 4 touch button control panel
    • Display: LCD display
    • Protocols: DMX512,RDM,Art-Net,sACN
    • DMX Protocol Modes: 4
    • Control Channels: 23/32/34/43
    • Firmware Upgrade: Upgrade via DMX link or USB stick

    Pan & Tilt

    • Pan Movement: 540°
    • Tilt Movement: 270°
    • Automatic Pan/Tilt position correction
    • Resolution: 16 bit
    • Fixation: Pan/Tilt lock

    Colors

    • Linear CMY color mixing
    • Linear CTO Color Correction: 2,700K-6,200K
    • 2 Color Wheels:
      • Color Wheel 1: 5 colors, plus open
      • Color Wheel 2: 4 colors, plus open

    Rotating Gobos

    • 2 Rotating Gobo Wheel:
      • Rotating Gobo Wheel 1:
        • 6 gobos, plus open
        • Gobo: Ф34 mm, lmage: Ф27.5 mm
      • Rotating Gobo Wheel 2:
        • 6 gobos, plus open
        • Gobo Slot 1-5: Ф34 mm, lmage: Ф26.5 mm
        • Gobo Slot 6: Ф31 mm

    Animation Wheel

    • A graphic animation wheel with continuous rotation in both directions, used alone or in combination with gobos to create the splendid water wave effect, and can be changed into other wheels

    Prism

    • 2 Combinable Rotating and Indexable Prisms: 1 x 4-facet circular prism, 1 x 4-facet linear prism, rotatable in both directions

    Frost Filter

    • 1 combinable light frost filter and 1 combinable medium frost filter

    Framing System

    • Shutter Blades: 4 blades, each with separate movement and full blackout
    • Rotation: ±60° of the complete framing system

    Other Effects

    • Outstanding strobe effect with variable speed
    • Smooth dimming 0-100% (4 user selectable dimming curves)
    • Motorized linear iris

    Electrical and Connectors

    • Input Voltage Range: 180-240Vac; 50/60Hz
    • Power Consumption: 2,265W
    • Power In/Out: Waterproof power connector in/out
    • Data In/Out: 3-pin or 5-pin waterproof XLR,RJ45 connector

    Physical Information

    • Fixture Dimensions:
      • Width: 465 mm (18.3″)
      • Depth: 365 mm (14.4″)
      • Height: 830 mm (32.7″)
      • Weight: 52.5 kg (115.7 lbs)

    Packing Information

    • Flight Case Dimensions:
      • Width : 812 mm (32.0″)
      • Depth : 610 mm (24.0″)
      • Height : 910 mm (35.8″)
      • Weight :
        • North American Standard: G.W.: 113.3 kg (249.8 lbs) (one-pack loader case)



    Dimensions

    Photometrics



    Video



    Colors

    Linear CMY Color Mixing

    CMY

    3027002402
    3027002403

    3027002404
    3027002405

    3027002406
    3027002407

    Linear CTO Color Correction

    2,700K-6,200K

    3027002408
    3027002409

    Color Wheel 1: 5 colors, plus open

    Red
    3027002389
    Slot 1

    Green
    3027002391
    Slot 2

    Pink
    302702392
    Slot 3

    Orange
    302702390
    Slot 4

    Blue
    3027002393
    Slot 5

    Color Wheel 2: 4 colors, plus open

    CTB
    3027005278
    Slot 1

    Yellow
    3027002386
    Slot 2

    UV
    302702388
    Slot 3

    Minus-Green
    3027002410
    Slot 4



    Gobos


    Rotating Gobo Wheel 1: 6 gobos, plus open

    Gobo: Ф34 mm, lmage: Ф27.5 mm

    Broken Circle
    3011001474
    Slot 1

    Eccentric Circles
    3011001475
    Slot 2

    Dream Tunne
    3011001476
    Slot 3

    Tiny Bubbles
    3011001477
    Slot 4

    Square Bar
    3011001478
    Slot 5

    Linear Breakup
    3011001479
    Slot 6

    Rotating Gobo Wheel 2: 6 gobos, plus open

    Gobo Slot 1-5: Ф34 mm, lmage: ф26.5 mm

    Gobo Slot 6: Ф31 mm

    Square Tunnel
    3011001481
    Slot 1

    Clouds
    3011001482
    Slot 2

    Mixed Beams
    3011001483
    Slot 3

    Multiple Angles
    3011001484
    Slot 4

    Grid
    3011001480
    Slot 5

    Diamond Glass A
    3015001218
    Slot 6



    Prisms/Frost Filters

    2 Combinable Rotating and indexable Prisms:

    1 x 4-facet circular prism, 1 x 4-facet linear prism, rotatable in both directions

    1 combinable light frost filter and 1 combinable medium frost filter

    4-Facet Circular Prism

    4-Facet Linear Prism

    Light Frost Filter

    Medium Frost Filter



    Zoom Range

    Animation Wheel

    A graphic animation wheel with continuous

    rotation in both directions, creating the

    splendid water wave effect, and can be changed into other wheels



    Framing System

    Shutter Blades: 4 blades, each with separate movement and full blackout

    Rotation: ±60° of the complete framing system
