Introducing ACME’s great innovation—the BLINDER LINE 10 IP: a highly versatile linear blinder light designed to elevate your lighting experience. This exceptional fixture showcases 10 high-powered 150W RGBAW LED sources, delivering mesmerizing color effects. The unit features ACME’s patented Smart Glass Technology, delivering unparalleled frosted aesthetics.

What sets this fixture apart is its dynamic features, including a powerful strobe effect and a distinctive filament lamp effect, ensuring that your lighting outcomes are nothing short of captivating. The BLINDER LINE 10 IP unit features tremendous output with selectable, smooth dimming curves, convenient color temperature presets and an extraordinary reach with a native 23° beam angle. The integrated interlocking connectors streamline the setup process, making it quick and effortless.

With an all-weather IP66 protection rating, this fixture is designed to withstand the element. Its comprehensive suite of advanced features ensures exceptional effects, allowing you to unleash your creativity without limitations. Elevate your lighting game with the BLINDER LINE 10 IP from ACME.

    Consultar precios

    También te recomendamos…

    Descripción

    Performance

    Light Source

    10 x 150W RGBAW LEDs

    LED Life Expectancy

    20,000 hours

    Total Lumen Output of Fixture

    26,300 lumens

    Beam Angle

    23°, 31°, 54° (W)

    24°, 32°, 54° (RGBA)

    Field Angle

    47°, 74°, 130° (W)

    49°, 79°, 131° (RGBA)

    Weight

    13.6 kg (30.0 lbs)



    Technical & Specification

    Model

    • Model Name: BLINDER LINE 10 IP
    • Model Code: BLB 10 IP

    Light Source

    • Light Source: 10 x 150W RGBAW LEDs
    • Total Lumen Output of Fixture: 26,300 lumens
    • Life Expectancy: 20,000 hours*
      *Source manufacturer specification

    Optical System

    • Beam Angle :
      • W: 23°, 31°, 54°
      • RGBA: 24°, 32°, 54°
    • Field Angle :
      • W: 47°, 74°, 130°
      • RGBA: 49°, 79°, 131°
    • DMX Controllable Smart Glass technology:
      • Patent No. :
        • CN216010577U
        • US11698183B1
        • DE202023101966U1
        • FR3134870B3

    Control

    • 4 touch button control panel
    • Display: OLED display
    • Protocols: DMX512,RDM,Art-Net,sACN
    • DMX Protocol Modes: 2
    • Control Channels: 14/55
    • Firmware Upgrade: Upgrade via DMX link

    Other Effects

    • Outstanding strobe effect with variable speed
    • Smooth dimming 0-100% (4 user selectable dimming curves)
    • Tungsten emulation during dimming
    • Individual pixel control and built-in color macro effects

    Electrical and Connectors

    • Input Voltage Range: 100-240Vac; 50/60Hz
    • Power Consumption: 600W
    • Power In/Out: Waterproof power connector in/out
    • Data In/Out: 3-pin or 5-pin waterproof XLR,RJ45 connector

    Physical Information

    • Fixture Dimensions:
      • Width: 1,000 mm (39.4″)
      • Depth: 103 mm (4.0″)
      • Height: 158.5 mm (6.2″)
      • Weight: 13.6 kg (30 lbs)

    Packing Information

    • Flight Case Dimensions 1:
      • Width : 1,220 mm (48.0″)
      • Depth : 610 mm (24.0″)
      • Height : 530 mm (20.9″)
      • Weight :
        • Standard : G.W.: 107 kg (235.9 lbs) (four-pack loader case)
    • Flight Case Dimensions 2:
      • Width : 1,220 mm (48.0″)
      • Depth : 610 mm (24.0″)
      • Height : 850 mm (33.5″)
      • Weight :
        • Standard : G.W.: 184 kg (405.7 lbs) (eight-pack loader case)
        • North American Standard : G.W.: 209 kg (460.8 lbs) (eight-pack loader case)
    • Carton Dimensions:
      • Width : 1,105 mm (43.5″)
      • Depth : 285 mm (11.2″)
      • Height : 200 mm (7.9″)
      • Weight :
        G.W.: 16 kg (35.3 lbs) (one-pack loader carton)

    Work Environment

    • Maximum Ambient Temperature:



    Dimensions



    Video









    Beam Angle

    Field Angle



    Descargas


    BLINDER LINE 10 IP Descargas Enlace
