Extensor CAT HDBaseT compatibles con DVI y HDMI – TP-HDMI HD-200TR

Beetek
SKU: TP-HDMI HD-200TR

Extensor CAT HDBaseT compatibles con DVI y HDMI

Admite la entrada DVI y HDMI
Interruptor automático entre DVI y HDMI
Extensión de un solo gato x
Resolución de soporte hasta 1920*1080@60 Hz

    Consultar precios

    ⓘ PRECIOS SIN IVA

    Descripción

    DVI y HDMI Soporte HDBaset Cat Extenders

    Admite la entrada DVI y HDMI
    Interruptor automático entre DVI y HDMI
    Extensión de un solo gato x
    Resolución de soporte hasta 1920*1080@60 Hz

    Especificaciones


    Name Specification
    Product Name HDMI1.4 HDBeasT Extender
    Model TP-HDMIHD-200TR
    Brand Beetek
    Signal HDMI 1.4
    Input Connector TX : HDMI Type A Female, DVI-D (18+1)
    RX: NEUTRIK water-proof RJ45
    Output Connector TX: NEUTRIK water-proof RJ45
    RX: DVI-D (18+1)
    CAT Cable Type CAT6 and above
    Indicator LED Power, Signal, Connection status, HDCP
    HDMI locking connector Yes
    Locking power connector Yes
    Power Consumption DC 24V 2A
    Working Temp -20°C ~ 70°C
    Material Metal mold
    Dimensions 142*91*37.5mm
    Weight TX: 381g; RX: 385g
    Package Dimensions 330*190*89mm
    Packaging Weight 1.1kg
    EDID Pass-through
    DDC Yes
    RS232 Yes
    HDMI Audio Yes
    3D Yes
    CEC Yes
    ARC Yes
    HDCP Yes
    HDR Yes
    XvYCC Color Space Yes
    POE Yes
    Technical Characteristics HDBeasT
    Resolution 1080 * 1920@60Hz
    Transmission Distance 100M
    Clock Bandwidth 340MHz *3
    Transmission Speed 10.2Gbps
    Balancing Chip Automatic equalization
    Reclocking Yes
    ESD Protection Yes
    Hot Plug Yes
    Delay Zero frame-delay
    Compression None
    Sampling Rate Bandwidth Range: 8~16bit
    Sampling Ratio RGB 4:4:4, YUV 4:4:4, YUV 4:2:2, YUV 4:2:0
    Input Signal Identification Input signal automatic recognition
    Output Signal Identification Prioritize the DVI signal;
    if the DVI signal is lost, automatically switch to the HDMI signal
