Cable adaptador de DP a HDMI 4K UHD PH904

Cable adaptador de DP a HDMI 4K UHD

Soporta 3840*2160@60HZ o 4096*2160@60HZ,RGB4:4:4;
Convierte la señal de DisplayPort a HDMI; Soporta EDID pass-through; Soporta CEC;Soporta salida de audio;
La cubierta del cable es de PVC compuesto resistente al desgaste. Ambos extremos vienen con tapones antipolvo desmontables con cadena de cinturón;
El conector HDMI se puede bloquear con un tornillo moleteado de acero inoxidable para que el sistema de conexión sea más estable.


Longitudes disponibles

PH904-2.5M 2.5M
PH904-5M 5M

    Consultar precios

    ⓘ PRECIOS SIN IVA

    Descripción

    Cable adaptador de DP a HDMI 4K UHD

    Soporta 3840*2160@60HZ o 4096*2160@60HZ,RGB4:4:4;
    Convierte la señal de DisplayPort a HDMI; Soporta EDID pass-through; Soporta CEC;Soporta salida de audio;
    La cubierta del cable es de PVC compuesto resistente al desgaste. Ambos extremos vienen con tapones antipolvo desmontables con cadena de cinturón;
    El conector HDMI se puede bloquear con un tornillo moleteado de acero inoxidable para que el sistema de conexión sea más estable.

    Especificaciones


    Name Specification
    Product Name DP 1.2a – HDMI 2.0 Adapter Cable
    Model PH904-xxM
    Brand Beetek
    Signal Type DP 1.2a, HDMI 2.0
    Conversion Method Active
    Input Connector Type DP Male
    Output Connector Type HDMI Type A Male
    Environmental Info RoHS 2.0 Compliant
    Connector Gold Plating Shell: 3μm; Pins: 15μm
    Connector Dimensions DP: 59.2*22*13.5mm; HDMI: 67.4*20.8*20.3mm
    Connector Structure (DP) Plug plate + Inner mold + Shielding case + Copper foil + SR outer mold + Shell + Protective cap
    Connector Structure (HDMI) Active PCB board + SR outer mold + Shell + Screw + Protective cap
    Internal Mold (DP) Transparent PE material
    Shielding Case (DP) Upper and lower assembled metal case
    Copper Foil (DP) Double-sided conductive copper foil
    SR Outer Mold 45P black PVC injection mold
    Shell DP: 45P PVC injection molded shell (UL, RoHS);
    HDMI: Zinc alloy upper and lower assembled shell
    Locking Connector (HDMI) Stainless steel screw
    Locking Connector (DP) Standard DP press-style locking mechanism
    Protective Cap Detachable cap with cord leash
    Components Conductor + Copper foil + Mylar + Braid + Jacket
    Conductor Material Stranded tinned copper
    Conductor Diameter 28AWG
    Braid Material 16*10 braided copper wire
    Shielding Rate 7 mesh 85% shielding rate
    Jacket Material 90P PVC (UL, RoHS)
    Cable Diameter 7.4mm
    Cable Color Fluorescent gray
    Cable Meter Marking Waterproof Yellow Text
    Velcro P-shaped Velcro Strap: 20*200mm
    EDID Yes
    DDC Yes
    HDMI Audio Yes
    3D Yes
    CEC Yes
    ARC Yes
    HDCP Yes
    HDR Yes
    XvYCC Color Space Yes
    ESD Yes
    Compatibility Backward compatible with DP 1.1 / 1.0 version
    Supported Resolutions 3840 x 2160@60Hz
    Clock Bandwidth 600MHz * 3
    Transmission Rate 18 Gbps
    Plug and Play Yes
    Delay Zero
    Compression None
    Deep Color Yes
    Color Sampling Rate RGB 4:4:4, YUV 4:4:4, YUV 4:2:2, YUV 4:2:0
    Electrical Test (Voltage) Voltage: DC 300V
    Impedance Test (Insulation) Insulation resistance: ≥ 10MΩ
    Impedance Test (Continuity) On-resistance: ≤ 2Ω
    Tensile Strength ≤400N
    Bending Angle 120°
    Operating Temperature -30℃~75℃

    Descargas


    Modelos disponibles

    ImageSKUDescription
    PH904-2.5MLongitud de cable: 2.5 m
    PH904-5MLongitud de cable: 5 m
